Aqua Inos Solutions

In house Fabrication, Welding, installation commissioning and maintenance / operation of plant.

Call US : +91-9583886221
Email: info@aquaions.com Get Quote's

S.No.	ITEM	Specifications	<10KLD	10 -25KLD	25-50 KLD	50-100 KLD	100-200 KLD
1.	Bar Screens	MSEP /S.S 304 Coarse & Fine	√	√	√	√	√
2.	Reactor Tanks/Aeration tanks	(M.S. Tank Epoxy coated inside & enamel painted outside) *¹	√	√	√	√	√
3.	Sewerage Transfer pumps	particle size – 35-40mm	√	√	√	√	√
4.	Filter Pumps	Horizontal, centrifugal	√	√	√	√	√
5.	Sludge Pumps	particle size – 8-10mm	√	√	√	√	√
6.	Dosing Pumps	0-6 LPH	√	√	√	√	√
7.	Air Blowers	Vertical ,Pressure Duty	√	√	√	√	√
8.	Diffusers	Coarse /Fine Bubble	√	√	√	√	√
9.	Bio- Media	Sp.area – 400 mm²	√	√	√	√	√
10.	Settler Media	750 mm vertically inclined	√	√	√	√	√
11.	Multi Grade Filter	FRP/M.S.E.P *²	√	√	√	√	√
12.	Activated Carbon Filter	FRP/M.S.E.P *³	√	√	√	√	√
13.	Motor Panel	Powder Coated centralized	√	√	√	√	√
14.	Sludge Dewatering System (Filter Press)	Manual pressurized filtration	X	X	X	√	√
15.	On-line pH meter	1-14 pH Value	√	√	√	√	√
16.	Pipe & Fittings	M.S./u-PVC	√	√	√	√	√
17.	Optional Fittings *⁴ Online Flow meter Screw Pumps Hydraulic Filter Press Ultra-violet Disinfection Ozonator Softener						√

Note: Beyond 200 KLD, STP will be designed according to space and flow in R.C.C tanks as well in M.S. tanks

*1 Tanks strength depends on flow, volume, and Hydraulic load and retention time. Tanks can also be FRP coated inside as per the client’s requirements
*2 Vessels can also available in M.S. epoxy coated/FRP Lined /Rubber lined as per the clients requirements.
*3 Vessels can also available in M.S. epoxy coated/FRP Lined /Rubber lined as per the clients requirements.
*4 These options will be available at client’s requirements and for further treatment of water.
